Quality Centrifugal Flow Fan & Industrial Centrifugal Fans Factory

On Aug 26th, the cracking furnace fans ordered by users in Kazakhstan were successfully delivered. There are 9 fans in this shipment, of which 6 fans are used for the gas generated by the pyrolysis furnace and conveyed under pressure. Inflammable and explosive gas, so there must be no leakage. According to the working conditions and specific requirements, we have thickened the fan, and the sealing device adopts a mechanical seal to ensure that the position where the main shaft and the casing are in contact will not leak gas. The transportation adopts frame packaging, which can effectively avoid bumps during loading and unloading. SIMO Blower’s industrial centrifugal fans can be widely used in various industrial systems, such as power generation, metallurgy, cement production, chemical industry , waste incineration systems, Industrial boiler systems, etc. Choose SIMO Blower, we will serve you wholeheartedly.

Centrifugal fans will wear due to long-term use during the application process. How to avoid the wear of centrifugal fans? First of all, we need to know that the wear of the centrifugal blower will be in many different positions, so different anti-wear measures need to be taken for them. At first, it’s necessary to do a good job on the blade surface. The common advantages of carburizing, plasma surfacing, spraying cemented carbide, and pasting ceramic sheets are to increase the hardness of the blade surface, which in turn improves the wear resistance of the blade to a certain extent. These methods are easy to use and low cost, but the coating wears quickly, and one treatment can last for 3 to 5 months. For blade wear, the impeller wear can be reduced to a certain extent by improving the blade structure, processing the working surface of the blower fan blade into a serrated shape, changing the hollow blade into a solid blade, and adding welding anti-wear blocks to the blade. Install the anti-wear cascade, and install the anti-wear cascade at the most easily worn place, which can prevent the particles from flowing to the rear disc and the blade root. In addition, the shape of the air inlet of the centrifugal fan should be selected reasonably, and the minimum inlet relative speed of the impeller should be ensured during the design, the number of revolutions of the fan should be reduced as much as possible, and the appropriate shape of the impeller flow channel should be selected.

The function of the damper is to pre-rotate the air to make the air flow into the impeller more smoothly. If a left-handed damper is installed on a right-handed fan, the wind will directly impact the blades, which is mainly manifested as overshoot load and strong vibration, if the damper is fully open, the current will rise straight, and in severe cases, the motor will burn out.     Today I will share with you how to distinguish the rotation direction of the damper. Let’s first look at this horizontal damper. First, we need to find the support rod of the damper as the base point (or take the air intake direction as the base point), and then observe the rotation direction of the linkage handle from fully closed to fully open, clockwise rotation is right rotation, counterclockwise rotation is left rotation.     How to distinguish the rotation direction of the damper installed on the fan? First, we stand on the motor side and observe the direction of the handle from fully closed to fully open (the direction of the switch will also be marked on the damper to help us better distinguish), clockwise rotation is right, and counterclockwise rotation is left.   Just I shared is the method of distinguishing the rotation direction of the petal-type damper. The common forms of the damper are single-plate, three-plate and louver. Among them, the single-plate and three-plate are not divided into rotation directions, and can be installed directly according to the direction of the air intake. Regarding the shutter-type damper, if you need to know more about it, you can contact us. https://www.youtube.com/watch?v=mUZxYOZKRNI&t=39s

Impeller is the heart of centrifugal fan. Different working conditions have different requirements for impeller forms of centrifugal fans. According to the blade Angle of impeller outlet, it can be divided into three types: forward type, radial type and backward type. Forward type blade, blade outlet Angle β2 > 90 °, the export of wind pressure is higher, but the efficiency is low, the forward type blade easily gathered impurities between the impellers, easy fouling, used for air flow, but requires higher area, wide application, blade generally narrower, quantity, type common to fan model has 9-10 series, 9-08 series high pressure fan.     Radial blade: the outlet Angle of the blade β2=90°, it has simple structure, low production cost, parameters between the forward type and the back type, low efficiency, because of its characteristics of not easy to scale, it is more used in the mine and heavy dust conditions. Backward blade: blade outlet Angle β2

Centrifugal fans can withstand the high temperature flue gas below 1000 degrees.     High temperature fan is a general name for a class of fans, suitable for conveying high temperature gas with slight corrosion, non-spontaneous combustion and working temperature below 1000℃. The dust content of medium should be less than 150mg/m3. It is widely used in chemical petroleum, metallurgical iron and steel, building materials, cement, environmental protection and other fields. According to the high temperature resistance level can be divided into four levels: one 80℃-300℃, two: 300℃-450℃, three: 450℃-600℃, four: 600℃-1000℃. In the design and selection of high temperature fan, the change of gas density under high temperature gas, the dimension expansion coefficient of fan components, and the selection of high temperature resistant materials should be fully considered. Different materials are classified as follows: FIBERglass: ≤100℃, carbon steel (Q390, Q460, HG785) : ≤500℃, stainless steel (304, 316L, 310S), dual-phase stainless steel 2205: ≤1000℃. High temperature resistance at the same time also consider the corrosive gas of high temperature flue gas, choose high temperature and corrosion resistant high quality materials. With the development and application of new technology and the continuous progress of high temperature resistance technology, high temperature fans will be applied in more industries and fields in the future, and high temperature fans will also provide more complete solutions for more industries.

Summer is rapidly becoming a memory, because there is no clean beach for visiting, at the weekend. “Beach litter is a serious environmental problem,” said Charlotte Coombes, Beachwatch Officer for the MCS. And it has becoming an international problem. More and more people take part in Environmental protection activities. That how to deal the rubbish has paid more attention. Rubbish is a kind of resources which was putted in wrong place. More people are considering the re-use of this resources. Electricity Power production has become the essential way to solve the garbage incineration. After negotiate with Vietnam customers on 13th January 2016, they visited SIMO BLOWER’s factory. The contract was signed. Recently, the customized high-pressure Garbage incinerator centrifugal fan has finished production. In order to make the garbage fully burn, SIMO BLOWER take the special design scheme of the blower fan. At present, the high pressure blower fan has been completed in the production, in the standardization of the blower fan, systematic testing, to ensure high-performance operation. Testing results show that the dynamic balance of the impeller is in line with the national standard of 3.0mm/s, and the vibration of the fan is in accordance with the standard of 4.5mm/s. SIMO BLOWER are willing to contribute the environmental protection. Let the sky bluer and the water cleaner.

A French electric power company which is committed to environmental protection came to SIMO BLOWER on June 14th, 2016. And they want to purchase a batch of induced draft fans for desulfurization and denitrification, and the diameter of impeller has to be 2500mm. Their purposes of visiting SIMO BLOWER this time are mainly for investigating our production strength, and having negotiations with SIMO BLOWER face to face about the technical and commercial schemes of the project. ●Company production strength: Clients inspected SIMO BLOWER's production process and quality control procedures, from the aspects of physical and chemical laboratory, cutting of raw materials, welding of the fan’s components, running testing, dynamic balancing and the annealing of the impeller, and etc. After the inspection, customers highly recognized SIMO's production strength. SIMO BLOWER has accumulated rich experience of fan’s design, manufacture, testing and so on, in the more than 60 years of fan production history. And SIMO BLOWER has got the certifications of ISO9001:2008, CE, ISO4001-2004, GB/T24001-2004, and the AA level. We have also got the science and technology progress award issued by the Government. And all of our fans are designed, developed, produced, and installed according to the GB/T19001-ISO9001 quality system. ●Technology: Our French friends raised a series of questions about the fan’s technology. They wanted to know: How to design the impeller and shaft? What is the effectiveness analysis of the fan? How to design the drawings? SIMO BLOWER adopts CAD computer-aided design for blowers, adopts CAPP computer-aided process design for key components, and uses finite element strength calculations for key components. We compare the multiple plans of variant design and model selection through relevant software. And blowers’ performance tests are done by computer automatic control. The customers were very satisfied, after visiting and inspecting SIMO BLOWER’s Technology Research and Development Center. ●Commercial schemes: The purchasing director, who came a long way from France, has very stringent requirements for the payment method. He raised questions on the advance payment and quality guarantee deposit. SIMO BLOWER’s business representatives explained to the customers that SIMO BLOWER’s payment method has always been in accordance with the current general international trade payment method. After hearing our explanation, the customers came to an agreement on the payment method with SIMO BLOWER. In order to stop our lovely Earth from becoming a garbage planet, we appeal to everyone to deal with garbage properly. If the garbage is handled well, we can turn the wastes into treasures.

The dust removal centrifugal blower fan have been arrived at the customer site in Russia. As the four sets steel factory induced draft blower fan’s diameter has reached 3000mm.The sales director and technical engineer of SIMO BLOWER was invited to Russia by customer, who will go to the application site to provide installation direction and operating service according to the requirement of the clients. Meanwhile, they will provide the technical training and service for clients. They will stay in Russia for more than 15 days. If you are interested in the blower fans, welcome come to application site have a visit. Contact us: service@simoblower.com.

From 2012 to 2013, SIMO BLOWER together closely with our European distributor in Russia, Ukraine, Guatemala and other countries jointly undertake a number of large-scale industrial construction projects. Industrial boilers, precipitators, desulfurization unit involved in the project we thermal power plants, metallurgical plants and steel used in the production line, denitrification device provides more than 30 sets of heavy duty centrifugal fans. One of the biggest capacity reached 850000m3/h, the maximum pressure reached 8000pa, the maximum diameter of the impeller reach 3.2meters. In these projects, SIMO BLOWER use their wealth of experience in design and manufacturing of heavy-duty fans, fan performance in terms of design, structural design, transportation, installation, commissioning, operator training, etc., to provide customers with a number of professional advice and tailor-made services, to help customers save a lot of costs and resources. Currently, heavy duty fans SIMO BLOWER provided for these projects have been put into use and is running well. SIMO BLOWER and European distributor of cooperation is extended to a wider field.

On November 18, 2013, Ukraine clients long-term cooperation with SIMO BLOWER, come to our factory inspection. Their size, appearance and quality of our products are carried on the inspection. They are very satisfied with the inspection result. For the further cooperation laid a solid foundation.
