| Place of Origin: | Henan China |
|---|---|
| Brand Name: | SIMO |
| Certification: | CE, ISO |
| Model Number: | SIMO Blower 4-10 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Export Wooden Case Packing, Steel pallet Packing |
| Delivery Time: | 15-35 Days |
| Payment Terms: | T/T, L/C, Payment Term Is Negotiable |
| Supply Ability: | 500 Sets Per Month |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Total Pressure: | 2139~8005Pa |
|---|---|---|---|
| Structure: | Cantilever | Application: | Cement Plant |
| Type: | Double Suction | Blades: | Backward Curve Blade |
| Blade Number: | 12 | Characteristics: | Low Pressure |
| Feature: | Coupling Driving | Impeller Testing: | Dynamic Blancing Adjusting |
| Cooling Type: | Air Cooling/Circulating Water Cooling | ||
| High Light: | Cement plant circulation fan,Double suction circulation fan,large air volume centrifugal fan |
||
Cement industry is one of industries which SIMO BLOWER is best at, SIMO BLOWER has lots of fan products for cement production line: air supply of rotary kiln fan, materials conveying fan, cooling of grate cooler fan, cooling of Rotary kiln cylinder fan, high temperature air induced fan and dust removing fan, etc, which can satisfy various applications of cement production line, such as air supply of rotary kiln, materials conveying, cooling of grate cooler, cooling of Rotary kiln cylinder, high temperature air induced and dust removing, etc. In the rugged environment of extreme high temperature and heavy wear, SIMO BLOWER’s cement fans can work reliably, and service life can be extended to 3 to 5 times.
| Product | Flow range | Pressure range | Speed ofmain shaft | Impeller diameter | |||
| m3/h | cfm | pa | mmwc | rpm | mm | in" | |
| 5-12C | 590-700735 | 347-412198 | 684-8687 | 69-886 | ≤4000 | 400-3300 | 15-130 |
| 5-11D | 590.4-560735 | 347-329845 | 684-9887 | 69-1100 | ≤4000 | 400-3300 | 15-130 |
| 7-09D | 4293-773605 | 2525-455062 | 4217-15694 | 430-1601 | ≤1450 | 1500-3500 | 59-138 |
| 4-10F | 67120-1050384 | 39482-617873 | 2081-9260 | 212-945 | ≤1450 | 1500-3150 | 59-125 |
| 9-10D | 273-81858 | 160-48152 | 348-15425 | 35-1573 | ≤4000 | 250-2000 | 9-79 |
| 5-11D | 590.4-560735 | 347-329845 | 684-9887 | 69-1100 | ≤4000 | 400-3300 | 15-130 |
| 4-10D | 10696-952530 | 6291-560312 | 615-8302 | 62-847 | ≤4000 | 400-3000 | 15-120 |
| 6-05D | 884-321950 | 520-189383 | 542-9112 | 55-930 | ≤4000 | 400-3000 | 15-119 |
Xinxiang SIMO Blower Co., Ltd which was founded in 1955, mainly designs and manufactures Centrifugal fans and Axial flow fans which are applied to industrial systems, which is the senior member of China General Machinery Industry Association (CGMA).SIMO BLOWER is one of the main large fan manufacturers in Central China, which owns more than 200 employees and the production capacity of 15000 sets one year.There is an advanced Air flow Test Laboratory in our company. We master mature fan designing, testing, manufacturing technology, and can design and manufacture multipurpose fans according to users' requirements. So, we are able to meet users' complex and professional applications. SIMO BLOWER's products have been widely used in thousands of customers' industrial systems, such as Coal-fired power, Metallurgy, Papermaking, Cement and Glass production, Chemical industry, Material handling, Sewage treatment, Waste incineration, Subway ventilation, Industrial boiler and Dust removal systems etc.
