| Place of Origin: | Henan China |
|---|---|
| Brand Name: | SIMO |
| Certification: | CE, ISO |
| Model Number: | SIMO Blower 4-10 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Export Wooden Case Packing, Steel pallet Packing |
| Delivery Time: | 15-35 Days |
| Payment Terms: | T/T, L/C, Payment Term Is Negotiable |
| Supply Ability: | 500 Sets Per Month |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Total Pressure: | 2139~8005Pa |
|---|---|---|---|
| Structure: | Double Suction | Application: | Forced Draft Of Industrial Kilns |
| Type: | Double Suction Blower | Blades: | Backward Curve Blade |
| Blade Number: | 12 | Characteristics: | Low Pressure |
| Feature: | Coupling Driving | Impeller Testing: | Dynamic Blancing Adjusting |
| Cooling Type: | Air Cooling/Circulating Water Cooling | ||
| High Light: | High Temperature Resistant Fan Blowers,Heat Resistant industrial centrifugal fan,Coupling Driving Industrial Centrifugal Blower Fan |
||
The operating range of the high-temperature fan can be within 800°C, and the performance parameters are: flow rate 3000-150000m3/h, total pressure 1500-11000Pa. The commonly used structural types are: Type A - cantilever or vertical - high temperature motor direct connection type C - cantilever or vertical - belt drive type D - cantilever or vertical - coupling connection type F - double support coupling connection type.
SIMO BLOWER adopts advanced research and development software for finite element analysis and flow channel optimization design; in terms of material selection, the creep strength, durable strength and permanent plasticity of the material are fully considered; in terms of thermal expansion design, the thermal expansion of the casing and shaft seal are fully considered The thermal expansion of the air inlet and the impeller, the tolerance of the impeller and the main shaft, and the linear expansion of the main shaft; in terms of heat dissipation, the heat dissipation of the bearing and the heat dissipation of the shaft seal are fully considered; for large F-type high-temperature fans, slow-rotation devices are considered design.
| Product | Flow range | Pressure range | Speed ofmain shaft | Impeller diameter | |||
| m3/h | cfm | pa | mmwc | rpm | mm | in" | |
| 6-11F | 52395-575176 | 30820-338340 | 30820-338340 | 234-1435 | ≤1450 | 1500-3600 | 59-142 |
| 6-12F | 15189-703455 | 8934-413798 | 2171-12259 | 221-1251 | ≤1450 | 1800-3300 | 70-130 |
| 6-2*11F | 1800-3300 | 1058-1942 | 2025-14068 | 107-199 | ≤1450 | 1500-3600 | 59-142 |
Xinxiang SIMO Blower Co., Ltd which was founded in 1955, mainly designs and manufactures Centrifugal fans and Axial flow fans which are applied to industrial systems, which is the senior member of China General Machinery Industry Association (CGMA).
SIMO BLOWER is one of the main large fan manufacturers in Central China, which owns more than 200 employees and the production capacity of 15000 sets one year.
There is an advanced Air flow Test Laboratory in our company. We master mature fan designing, testing, manufacturing technology, and can design and manufacture multipurpose fans according to users' requirements. So, we are able to meet users' complex and professional applications. SIMO BLOWER's products have been widely used in thousands of customers' industrial systems, such as Coal-fired power, Metallurgy, Papermaking, Cement and Glass production, Chemical industry, Material handling, Sewage treatment, Waste incineration, Subway ventilation, Industrial boiler and Dust removal systems etc.
