Flue Gas Centrifugal Blower Fan Industrial Air Filtration System

Basic Information
Place of Origin: Henan China
Brand Name: SIMO
Certification: CE, ISO9001:2008,TUV
Model Number: SIMO Blower 7-09
Minimum Order Quantity: 1 Set
Price: 300-5000 USD
Packaging Details: Export Wooden Case Packing, Steel pallet Packing
Delivery Time: 15-35 Days
Payment Terms: T/T, L/C, Payment Term Is Negotiable
Supply Ability: 500 Sets Per Month
Application: Industrial Ventilation Feature: High Performance
Bearing Type: Rolling Bearing Category: Blower
Main Shaft: High-strength Carbon Structural Steel Medium: Clean Air/Dusty Air
High Light:

flue gas blower

,

single inlet centrifugal fan

Industrial Air Filtration System Flue Gas Centrifugal Blower Fan



Introduction



The Industrial Air Filtration System Flue Gas Centrifugal Blower Fan is the latest series of high-efficiency industrial centrifugal fan developed by our company. It has the highest efficiency of 85.4%.

The Industrial Air Filtration System Flue Gas Centrifugal Blower Fan belongs to small flow and medium pressure series.

The Industrial Air Filtration System Flue Gas Centrifugal Blower Fan has stable and high performance and is widely used in environmental dust removal, material transportation and equipment matching in industrial fields.

This series of Centrifugal Blower Fan is a new type of high efficiency industrial fan in the field of small flow and medium pressure.The current collector and impeller front plate are processed by advanced spinning process and ensure precision.V-belt driving and coupling driving type fan are equipped with integral bearing box, which has good lubrication, stable operation and long bearing life.



Technical data



series model

Flue Gas Fan

Rotation Speed
(r/min)

Flue Gas Fan

Total Pressure
(Pa)

Flue Gas Fan

Air Capacity
(m³/h)

Power
(kW)

7-09

Flue Gas Fan

5C 3030 2982 ~ 3456 4486 ~ 8971 11 ~ 15
5.6C 2360 2623~2264 4909~9817 11
7.1C 1830 ~ 2450 2188 ~ 3862 7757~20771 15 ~ 30
8C 1910 3517~3034 11582~23164 30
9C 1570 3002~2591 13555~27111 30
10C 1470 ~ 1650 2806 ~ 4109 17410 ~ 36478 45 ~ 55



FAQ



1. What parameters need to be provided when you design the industrial centrifugal fans ?

Answers: Air flow, total pressure or static pressure, inlet temperature, local voltage and frequency, Altitude etc.

If there is flammable and explosive gas, or big dust loading in the medium, please also inform the designer.

2. How about your company’s pre-sales service and after-sales service ?

Answers: Before our cooperation, we have the professional technical team to help you make the technical solution according to your working condition, to make sure the centrifugal fan efficiency operation.

After sales service, we will offer 12 months’ repairing service, and provide lifelong follow-up services. Besides, our engineers are available for going abroad to offer the repairing service.

3. Does your company have qualifications ?

Answers: SIMO Blower has obtained ISO 9001-2008, CE, BV certifications and so on.





Flue Gas Centrifugal Blower Fan Industrial Air Filtration System 0

Flue Gas Centrifugal Blower Fan Industrial Air Filtration System 1
