Carbon Steel High Temperature Centrifugal Fan Heavy Duty Backward Curved
Backward Curved High Temperature Centrifugal Fan
,Heavy Duty High Temperature Centrifugal Fan
,Carbon Steel High Temperature Blower Fan
Carbon Steel Heavy Duty Backward Curved High Temperature Centrifugal Fan
Introduction
The 8-17 series high temperature centrifugal blower is designed for applications requiring high pressure.
Customized design according to customer's performance requirements, and optimized by CFD technology, the energy consumption is lower than similar models.
There are a variety of options to choose from.
Technical data
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
|---|---|---|---|---|---|
| 8-17 | 7.1D | 2900 | 10728～11973 | 768～2919 | 11～18.5 |
| 8D | 2930 | 14297～15680 | 1110～4219 | 22～37 | |
| 9D | 2930 | 18308～20250 | 1591～6019 | 37～55 |
Advantages and Features
1. It can output high outgas pressure and can work at higher medium temperature, suitable for any industrial occasion where high pressure & high temperature gas needs to be delivered.
2.When the airflow resistance is increased, the motor load will be automatically reduced and the motor will not be burnt.
3. The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
-
