High Temperature Centrifugal Fan
>
Carbon Steel 6019M3/Hr High Temperature Centrifugal Fan Coupling Driven High Volume

Carbon Steel 6019M3/Hr High Temperature Centrifugal Fan Coupling Driven High Volume

Product Details:
Place of Origin: Henan China
Brand Name: SIMO
Certification: CE, ISO9001:2008,TUV
Model Number: SIMO Blower 8-17
Detail Information
Place of Origin:
Henan China
Brand Name:
SIMO
Certification:
CE, ISO9001:2008,TUV
Model Number:
SIMO Blower 8-17
Impeller Test:
Ultrasonic Flaw Detection
System Type:
Single Inlet, Overhang Type
Medium:
Clean Air/Dusty Air
Warranty:
1 Year
Bearing Cooling:
Air Cooling Or Circulating Water Cooling
Lubrication:
Oil Bath Lubrication
High Light:

High Light

High Light:

6019M3/Hr High Temperature Centrifugal Fan

,

20250pa High Temperature Centrifugal Fan

,

6019M3/Hr high temp blower fan

Trading Information
Minimum Order Quantity:
1 Set
Price:
Negotiable
Packaging Details:
Export Wooden Case Packing, Steel pallet Packing
Delivery Time:
15-35 Days
Payment Terms:
T/T, L/C, Payment Term Is Negotiable
Supply Ability:
500 Sets Per Month
Product Description

Carbon Steel Coupling Driven High Volume High Temperature Centrifugal Fan



Introduction



The 8-17 series high-pressure small-flow fan is designed for applications requiring high pressure.

Under the premise of ensuring a certain amount of air, the full pressure can reach the high pressure requirement.

It is mainly used for blasting furnace blast and other forced air supply, and can also be used for tunnels to exhaust or supply air through hard pipes.

The fans are divided into general type, explosion-proof type, anti-corrosion type and high temperature type.



Product features



1. It can output high outgas pressure and can work at higher medium temperature, suitable for any industrial occasion where high pressure & high temperature gas needs to be delivered.

2. In the case of common base, the installation is very simple and requires little support from a professional technician.

3. The bearing housing is reserved for the installation position of the temperature and vibration sensors, and the fan operation monitoring device can be conveniently installed.

4. When the airflow resistance is increased, the motor load will be automatically reduced and the motor will not be burnt.

5. Customized design according to customer's performance requirements, and optimized by CFD technology, the energy consumption is lower than similar models.



Technical specifications



series model Rotation Speed
(r/min)
Total Pressure
(Pa)
Air Capacity
(m³/h)
Power
(KW)
8-17 7.1A 2900 1072811973 7682919 1118.5
8A 2930 1429715680 11104219 2237
9A 2930 1830820250 15916019 3755


FAQ



1,Q: What’s the MOQ of your company?

A: The MOQ is 1set.

2,Q: How long is the delivery time?

A :     A:5-35 days.

3,Q : What’s your payment terms?

   A : T/T, L/C, or Negotiable.

4,Q: What’s your warranty?
   A: 1 year.
5,Q: Is your company factory or trade company?

   A: We have our own factory, our type is factory +trade.
