Aluminium Alloyed Long Life Centrifugal Ventilation Fans Drying
2900r/min Centrifugal Ventilation Fans
,Centrifugal Ventilation Fans Aluminium Alloyed
,Centrifugal Ventilation Fans Drying
Aluminium Alloyed Long Life Centrifugal Ventilation Fans Drying
Introduction
The 5-10 series ventilator is a high efficiency and energy saving product developed by our company, which is used for ventilation and exhaust system of smelting, chemical, medicine and dust removal production lines.
High aerodynamic performance heavy duty centrifugal fans. Radial bladed impellers with an inducer section at the inlet.
Technical data
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
|---|---|---|---|---|---|
| 5-10 | 4D | 2900 | 1606～1232 | 3007～5152 | 3 |
| 4.5D | 2880 | 2004～1538 | 4252～7284 | 5.5 | |
| 5D | 2900 | 2509～1925 | 5873～10062 | 7.5 | |
| 5.4D | 2900 | 2927～2246 | 7398～12675 | 11 | |
| 6D | 2500 | 2685～2060 | 8749～14989 | 15 | |
| 8D | 2000 | 3055～2344 | 16591～28424 | 30 | |
| 9D | 2000 | 3867～2967 | 23623～40471 | 45 | |
| 10D | 1600 | 3055～2344 | 25923～44413 | 45 |
FAQ
1,Q: What’s the MOQ of your company?
A: The MOQ is 1set.
2,Q: How long is the delivery time?
A : A:5-35 days.
3,Q : What’s your payment terms?
A : T/T, L/C, or Negotiable.
4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?
A: We have our own factory, our type is factory +trade.
Application
Centrifugal fan is applied in industrial boiler, (centrifugal fan can be applied in industrial boiler,) it also can be applied in industrial kilns, blast furnace, Industrial waste heat recovery device, Electrolytic aluminium production line air purification system and other industrial work environment.
-
