Industrial Waste Gas Treatment Draft Induction Blower Single Inlet Long Lifetime

Basic Information
Place of Origin: Henan China
Brand Name: SIMO
Certification: CE, ISO9001:2008,TUV
Model Number: SIMO Blower 8-06
Minimum Order Quantity: 1 Set
Price: 300-5000 USD
Packaging Details: Export Wooden Case Packing, Steel pallet Packing
Delivery Time: 15-35 Days
Payment Terms: T/T, L/C, Payment Term Is Negotiable
Supply Ability: 500 Sets Per Month
Application: Industrial Ventilation Feature: High Performance
Current Type: AC Lubrication: Oil Bath Lubrication
Color: Customer's Requirement Power Source: Three Phase AC Motor
High Light:

induced draught fan

,

induced draft blower

Single Inlet Long Lifetime Industrial Waste Gas Treatment Induced Draft Blower



Introduction



The Single Inlet Long Lifetime Industrial Waste Gas Treatment Induced Draft Blower Fan is designed to work in the high efficiency area to achieve energy saving when operating under variable operating conditions.

It is jointly designed by the fan energy-saving group of the Ministry of Machinery Industry and organized by the national fan industry.

It’s a high-performance product promoted by the State Economic Commission and the Ministry of Machinery Industry.

It has the advantages of high efficiency, low noise, wide performance and high efficiency curve.

Applicable to industrial boilers of 5 ~ 35 tons/hour, the similar intake conditions and performance can be adapted, but the maximum temperature should not exceed 250 °C.

The dust removal device with a dust removal efficiency of not less than 85% must be installed before the induced draft fan, in order to reduce the dust content of the flue gas entering the fan, which not only reduces the pollution of the flue gas to the environment, but also reduces the wear of the dust on the fan. It’s conducive to extending the life of the fan.



Technical data



series model

Induced Draft Blower

Rotation Speed
(r/min)

Induced Draft Blower

Total Pressure
(Pa)

Induced Draft Blower

Air Capacity
(m³/h)

Power
(kW)

8-06

Induced Draft Blower

8C 1450 19992166 398011055 7.511
9C 14501550 26483236 566716825 18.5


Advantages and Features



1. Single Inlet Long Lifetime Industrial Waste Gas Treatment Induced Draft Blower is capable of outputting higher gas pressures and providing more gas flow with lower noise.

2. In the case of common base, the installation is very simple and requires little support from a professional technician.

3. The motor shaft is elastically connected with the drive shaft, and it is not necessary to constantly tighten the belt or replace the belt, and the maintenance workload is small.

4. Fans with an impeller diameter of less than 1400 mm operate at a normal temperature fan system, eliminating the need for additional bearing cooling devices, reducing the amount of user investment and maintenance.



FAQ



1. What parameters need to be provided when you design the industrial centrifugal fans?

Answers: Air flow, total pressure or static pressure, inlet temperature, local voltage and frequency, Altitude etc.

If there is flammable and explosive gas, or big dust loading in the medium, please also inform the designer.

2. How about your company’s pre-sales service and after-sales service?

Answers: Before our cooperation, we have the professional technical team to help you make the technical solution according to your working condition, to make sure the centrifugal fan efficiency operation.

After sales service, we will offer 12 months’ repairing service, and provide lifelong follow-up services. Besides, our engineers are available for going abroad to offer the repairing service.

3. Does your company have qualifications?

Answers: SIMO Blower has obtained ISO 9001-2008, CE, BV certifications and so on.
