Steam Boiler Large Centrifugal Blower With Forward Blade CE ISO

Steam Boiler Large Centrifugal Blower With Forward Blade CE ISO
Brand Name
SIMO
Product Model
SIMO Blower 9-11
Certificate
CE, ISO9001:2008,TUV
Country Of Origin
Henan China
MOQ
1 Set
Unit Price
300-5000 USD
Payment Method
T/T, L/C, Payment Term Is Negotiable
Supply Capacity
500 Sets Per Month
Product Details
Highlight:

backward curved centrifugal blower

,

large centrifugal blower
Application: Industrial Ventilation
Feature: High Performance
Color: Customer's Requirement
Blade: Forward / Backward/Backward Curved
Electric Current Type: AC
Medium: Clean Air/Dusty Air
Product Description
Detailed Specifications And Features

Large Capacity Steam Boiler Explosion Proof Centrifugal Blower Fan



Introduction



The Large Capacity Steam Boiler Explosion Proof Centrifugal Blower Fan has a large flow rate and moderate pressure.

This fan is designed for the purpose of using industrial boiler to work in the high-efficiency area and achieve the energy-saving target.

The fan is suitable for equipped with economizer (heater) and smoke and dust removal device.

It is a high-efficiency energy-saving product jointly designed by the national fan industry and organized by the national wind power industry and the Ministry of Machinery Industry.

In the case of using the common base, the installation is very simple and basically does not require the support of professional technicians.The motor shaft is elastically connected with the drive shaft. It is not necessary to tighten the belt or replace the belt frequently, and the maintenance workload is small.The fan system running at normal temperature with an impeller diameter of less than 1400 mm does not require additional configuration of bearing cooling device, which reduces the user's investment and maintenance workload.



Technical data



series model

Centrifugal Blower

Rotation Speed
(r/min)

Centrifugal Blower

Total Pressure
(Pa)

Centrifugal Blower

Air Capacity
(m³/h)

 Power
(kW)

9-11

Centrifugal Blower

 4D 2900 2285～2452 3297～6594 5.5～7.5
4.5D 2900 2893～3060 4695～9389 11～15
5D 2900 3570～3854 6440～12880 15～22
5.6D 2900 4482～4805 9048～18095 30～45
6.3D 1450 1422～1500 6441～12882 7.5～11
7.1D 1450 1804～1942 9220～18439 11～18.5
8D 1450 2285～2462 13189～26378 18.5～30
9D 1450 2893～3099 18779～37558 37～55
10D 1450 3570～3854 25760～42933 55～90
11.2D 960～1450 1961～4835 23961～72381 30～160
12.5D 730～960 1412～2638 25329～66620 22～90
14D 730～960 1775～3305 35586～93596 45～160
16D 730～960 2314～4295 53120～139712 75～280


Application



Explosion Proof Centrifugal Blower Fan is widely used in the cement industry, building materials industry, environmental protection industry, metallurgical industry, power industry projects such as large-scale dust collector, industrial boilers, ventilation systems, cooling.
