AC Industrial Centrifugal Fans Low Pressure Large Capacity Gas Delivery Fan

Basic Information
Place of Origin: Henan China
Brand Name: SIMO
Certification: CE, ISO9001:2008,TUV
Model Number: SIMO Blower 4-14
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Export Wooden Case Packing, Steel pallet Packing
Delivery Time: 15-35 Days
Payment Terms: T/T, L/C, Payment Term Is Negotiable
Supply Ability: 500 Sets Per Month
After-sales Service Provided: Field Installation, Commissioning And Training Power Source: Three Phase AC Motor
Bearing Cooling: Air Cooling Or Circulating Water Cooling Mounting: Free Standing
Delivery Time: 30 Days Electric Current Type: AC
High Light:

AC Industrial Centrifugal Fans

,

Low Pressure Industrial Centrifugal Fans

,

Large Capacity Gas Delivery Fan

Industrial Centrifugal Fans Low Pressure Large Capacity Gas Delivery Fan



Introduction Of Centrifugal Fan



The 4-14 series centrifugal fan is suitable for indoor ventilation in general factories and large buildings.

It can be used to input gas as well as to output gas.

The motor selects the high-efficiency energy-saving motor of China's leading motor manufacturing enterprise (can also install the brand motor required by users), the quality is reliable, and the energy consumption is lower.



Technical data



series model Rotation Speed
(r/min)
Total Pressure
(Pa)
Air Capacity
(m³/h)
Power
(kW)
4-14 2.8A 1450 ~ 2900 166 ~ 970 565 2262 0.55 ~ 1.1
3.15A 1450 ~ 2900 215 ~ 1245 912 3435 0.55 ~ 1.5
3.55A 1450 ~ 2900 274 ~ 608 13545013 0.55 ~ 3
4A 1450 ~ 2900 353 ~ 2069 19927281 0.75 ~ 4
4.5A 1450 ~ 2900 460 ~ 2657 289540585 1.1 ~ 7.5
5A 1450 ~ 2900 578 ~ 3314 402514490 2.2 ~ 15



Product Advantages



1. Made of high quality carbon steel, Stainless steel or other metal materials can also be used according to user requirements.

2. After the production is completed, all products are tested for running and vibration values for reliable operation.

3. The impeller is annealed to completely eliminate the internal stress generated during welding, ensuring that the impeller does not undergo creep and cracks.



FAQ



1. What parameters need to be provided when you design the Heat Dissipation Power Plant Blower Fan?

Answers: Air flow, total pressure or static pressure, inlet temperature, local voltage and frequency, Altitude etc.

If there is flammable and explosive gas, or big dust loading in the medium, please also inform the designer.



2. How about your company’s pre-sales service and after-sales service?

Answers: Before our cooperation, we have the professional technical team to help you make the technical solution according to your working condition, to make sure the centrifugal fan efficiency operation.

After sales service, we will offer 12 months’ repairing service, and provide lifelong follow-up services. Besides, our engineers are available for going abroad to offer the repairing service.



3. Does your company have qualifications?

Answers: SIMO Blower has obtained ISO 9001-2008, CE, TUV certifications and so on.
